Citizen CL-S631 II LLabel Printer

Citizen CL-S631 II

Our desktop range is designed to provide simple, low-cost, high quality printing and the best-in-class CL-S631II offers the finest resolution, providing 300 dpi for the reproduction of logos, pictures and EAN-compliant barcodes. The CL-S631II is supplied as standard with Cross-Emulation™ technology with both Zebra® and Datamax® emulations, plus a range of connectivity options including USB, Ethernet and WiFi.

  • Direct and thermal transfer printing

  • Robust all-metal mechanism

  • Easy media loading

Download Datasheet

Printing Media Technical-Specifications Warranty / Safety

Printing

Printing Technology Thermal Transfer + Direct Thermal
Printing Resolution 300 dpi
Print Speed (maximum) 4 inches per second (100 mm/s)
Print Width (maximum) 4 inches (104 mm)

Media

Media Width (min to max) 0.5 - 4.6 inches (12.5 - 118 mm)
Media Thickness (min to max) 63.5 to 254 µm
Media Sensor Fully adjustable gap, notch and reflective black mark
Media Length (min to max) 0.25 to 64 inches (6.35 to 1625.6 mm)
Roll Size (max), Core Size Inside diameter 5 inches (125 mm)
External diameter 8 inches (200mm) Core size 1 inch (25mm)
Ribbon winding & type Ink side in or out, switch selectable. Wax, Wax/Resin or Resin Type
Ribbon size 2.9 inches (74mm) maximum outside diameter. 360 metres length. 1 inch (25mm) core
Ribbon system ARCP™ automatic ribbon tension adjustment


Technical-Specifications

RAM (standard Memory) 32MB total, 8MB available for user
Flash (Non-Volatile Memory) 16 MB total, 4MB available for user
Main Interface Dual Interface Serial (RS-232C), USB (version 2.0, full speed)
Optional Interfaces
  • Wireless LAN 802.11b and 802.11g standards, 100 metres, 64/128 bit WEP, WPA, up to 54Mbps
  • Ethernet (10/100 BaseT)
  • Parallel (IEEE 1284 compliant)
Mechanism Hi-Lift™ metal mechanism with wide opening head
Control panel 4 buttons and 4 LEDs
Drivers and software Free-of-charge on CD with printer, including support for various platforms
Cutter Guillotine type, Dealer Installable
Emulations (Languages)
  • Cross-Emulation™ - autoswitch between Zebra®
    and Datamax® emulations
  • CBI™ BASIC Interpreter
  • Eltron® EPL2®
  • Zebra® ZPL2®
  • Datamax® DMX
Case Hi-Open™ industrial ABS case with safe close
Size (W x D x H) and Weight 231 x 289 x 270 mm, 4.5 Kg

Warranty / Safety

EMC & safety standards
  • CE
  • TUV
  • UL
  • FCC
  • VCCI
Warranty 2 years on printer. 6 months or 50 Kms printhead


Paper load

Durable design - Citizen's proven Hi-Lift™ all-metal mechanism

Media support

Large media capacity - holds rolls up to 5 inches (127 mm).

Paper Width

Variable paper width - 0.5 inches (12.5 mm) – 4.6 inches (118.1 mm)

Paper thickness

Paper thickness up to 0.250mm.

Printing Speed

Fast print out - 4 inches per second (100 mm per second).

Tear bar

Standard tear-bar for perforated tags

Ribbon

  • No more unreadable labels - the ARCP™ ribbon control technology assures clear prints.
  • Wide range of ribbon options - Uses up to 360 metres inside and outside wound ribbons.

Case

Hi-Open™ case for vertical opening, no increase in footprint and safe closing.

Media sensor

  • Adjustable media sensor
  • Black mark sensor
  • Label gap sensor

Other

  • Internal power supply for reliability
  • Low space requirement - integrated power supply enables clean work station


Accessories And Options


  • Auto cutter
  • Basic peeler

Naturally Citizen Green Concept


  • ENERGY STAR® compliant
  • Recyclable packacking

Operating Systems


  • Windows 7 & 10
  • Windows Server 2012, 2016 & 2019
  • Linux and Mac OS/X
  • Zebra® ZPL2®
  • Cross-Emulation™ - Automatically switch between Zebra® ZPL® and Datamax®
  • BASIC Interpreter - for data stream processing
  • Linux CUPS
  • Datamax® DMX
  • EPL2 Emulation
  • IOS
  • Android
  • Windows 11
  • Windows Server 2022

Applications


  • Healthcare
  • Retail
  • Manufacturing
