Citizen CT-E601

Flexible, high performance, top-exit printing.


Contact Us
Citizen CT-E601 POS Printer

Citizen CT-E601

Protected by innovative self-protective housing the CT-E601 is the ultimate printer that protects your printing station and suppresses bacteria. With an SIAA brand mark that fulfils ISO 22196, it is engineered to deliver effective results against bacteria growth and is designed to the highest industry standards. Perfect for environments where cleanliness and hygiene are key.
The CT-E601 provides users with flexible connection options including a singular USB interface model with optional interface card slot to home Serial, Bluetooth, Ethernet, Wireless LAN and Lightning connections.

  • Innovative self-protective housing and disinfectant ready design.
  • Anti-curl function / Stylish, modern design.
  • One hand media change.
  • Small footprint with the ability to fit alongside POS systems and cash drawers.

Printing Media Technical-Specifications Warranty / Safety

Printing

Printing Technology Direct Thermal
Printing Resolution 203 dpi
Print Speed (maximum) 350 mm/sec.
Print Width (maximum) 72 mm

Media

Media type Thermal receipt paper
Media Width (min to max) 57.5 - 79.5 (+/- 0.5 mm)
Media Thickness 53 to 85 μm
Media Sensor Paper end
Paper sensor Paper near end sensor
Roll Size (max), Core Size 83 mm outside diameter

Technical-Specifications

Flash (Non-Volatile Memory) 8 MB
Cutter Guillotine type, full and partial
Reliability 200 Million pulses or 150 Km, 2 million cuts
Control panel 2 buttons, 5 LEDs
Main Interface USB 2.0 full speed
Optional Interface
  • Ethernet
  • Ethernet + USB host
  • USB with hub
  • Serial (RS-232C compliant)
  • Compact Wireless LAN
  • Bluetooth with Apple™ MFi compatibility
  • Premium Wireless LAN
Drivers and software Free-of-charge from Citizen Systems website,
including support for various platforms
Emulations (Languages) ESC/POS™
Barcodes
  • Code3of9
  • UPC-A
  • UPC-E
  • EAN-13 (JAN-13)
  • EAN-8(JAN-8)
  • Codabar, ITF
  • CODE39
  • CODE93
  • CODE128
  • CODABAR(NW-7)
  • PDF 417
  • QR Code
  • GS1-Databar
  • Composit Symb
Character table / Code page 128 characters, 16 pages
Number of columns
  • Up to 48 digits (12 × 24: font A)
  • Up to 64 digits (9 ×24: font B)
  • Up to 72 digits (8 ×16: font C)
  • Maximum 26 digits (24×24: Kanji Font A)
Power supply 100 – 240V, 50-60 Hz.
Operation environment +5 to +45°C, 10% - 90% RH, non condensing
Storage environment -20 to +60°C, 10% - 90% RH, non condensing
Case Stylish flat-top case and top loading
Size (W x D x H) and Weight 108 x 125 x 165 mm, 1.3Kg

Warranty / Safety

EMC and safety standards
  • CE
  • TUV
  • UL
  • C-UL
  • FCC
  • VCCI
Warranty 2 years including head and cutter

Paper load

Quick and easy media changing - drop-in paper loading.

Printing Speed

Fast print out of receipts - up to 350mm per seconds.

Paper exit

Top exit - ideal for all retail applications

Paper width

Variable paper width – 58 and 80 mm

Paper exit

Front exit, top loading

Media sensor

Paper near end sensor

  • Mobile-POS ready

  • Easy notification - built-in buzzer

  • Page mode

  • Easy customisation by software

  • Barcode printing

  • Same height as cash drawers

  • Cash drawer connection

  • Case colour: Available in black or white

  • Wall mount installation

  • Disinfectant ready

  • Self protective housing

Accessories And Options

  • Cutter (full / partial)

Naturally Citizen Green Concept

  • Small footprint
  • Print, Sleep and Standby modes

Easy maintenance

  • Tool-free maintenance

Operating Systems

  • Windows 7 & 10
  • Windows XP, Vista, 7, 8.1 und 10, Server 2008R2, 2012
  • OPOS
  • JavaPOS
  • ESC/POS® emulation
  • Linux CUPS
  • Linux and Mac OS/X
  • iOS
  • Android
  • Development kits for Windows Mobile, Android, Blackberry, Symbian, etc.
  • Windows 11
  • Windows Server 2022

Applications

  • Hospitality
  • Retail
  • Healthcare
  • Journal
  • Kiosk
  • Kitchen
  • Pharmacy
  • Queue Management
